Power Lift Desk Control System

5 0 Reviews
product description of Power Lift Desk Control System ·JSM-3.1-0.3W is an energy-saving control box, suitable for multi-seat lift tables · Through the transfer box, one power supply can supply power to multiple control boxes at the same time. Up to 48 column lifts can be controlled. · Equipped...
Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

The Adjustable Table Base Control Box by JS Technology is engineered for desk frame manufacturers and OEM/ODM partners seeking seamless integration and versatile compatibility in height-adjustable desk designs. This robust 3-motor control system offers unmatched flexibility, enabling manufacturers to create ergonomic, customizable desk solutions for diverse applications, from office furniture to industrial workstations.


Why Choose the Adjustable Table Base Control Box?

Designed with desk frame manufacturers in mind, this control box is the ideal choice for businesses prioritizing adaptability and ease of integration. Its open control logic supports secondary development, allowing OEM partners to tailor functionalities to specific desk designs. Whether you're producing L-shaped corner desks, multi-leg conference tables, or compact home office solutions, this control box ensures precision and reliability.


Key Features and Benefits

  • Universal Compatibility: Seamlessly integrates with various desk frame configurations, including 2, 3, or 4-leg designs, supporting square, round, or custom lifting columns.

  • Open Control Logic: Enables OEM/ODM partners to customize control algorithms, ideal for bespoke desk solutions or branded product lines.

  • Compact and Modular Design: Simplifies installation into diverse desk frames, reducing assembly time and costs for manufacturers.

  • Advanced Safety Features: Includes overheating protection, motor short-circuit detection, and anti-pinch technology to ensure safe operation.

  • Energy Efficiency: Ultra-low standby power consumption (<0.3W), compliant with global energy standards.


Electric Stand Desk Controller

wholesale switch panel 7-key USB

Technical Specifications

  • Model: JSM-3.1-0.3W

  • Input: 100-240V, 50/60Hz, 8A

  • Output: 24Vdc, 110VA per motor, 330VA total

  • Maximum Power: 450W

  • Duty Cycle: 2min ON / 18min OFF

  • Certifications: CE, UL, FCC, SAA, RCM


China 3 motor control box label

China 3 motor controller certificates

These specifications translate into reliable performance for manufacturers, enabling smooth height adjustments across a wide range of desk sizes and weights, with minimal maintenance required.


Applications and Industry Use Cases

The Adjustable Table Base Control Box is tailored for:

  • OEM Furniture Manufacturers: Perfect for companies producing height-adjustable desk frames for office, home, or industrial use.

  • Ergonomic Furniture Designers: Supports innovative desk designs, such as multi-user workstations or modular conference tables.

  • Custom Furniture Brands: Ideal for businesses offering branded, tailored desk solutions with unique control requirements.


Comparison Table: Adjustable Table Base Control Box vs. Standard Control Boxes


Feature Adjustable Table Base Control Box Standard Control Box
Compatibility Supports multiple frame types (2-4 legs, custom columns) Limited to specific frame designs
Control Logic Open for secondary development Fixed, non-customizable
Installation Modular, compact design Bulkier, complex wiring
Safety Features Anti-pinch, overheating protection Basic safety only


Frequently Asked Questions (FAQs)

  1. Can this control box be integrated with non-standard desk frames?
    Yes, its modular design and open control logic make it compatible with a wide range of custom desk frames, including unique column shapes and configurations.

  2. Is it suitable for small-batch OEM production?
    Absolutely, we support low MOQs (1000 PCS) and offer tailored solutions for small to large-scale production runs.

  3. What support is available for secondary development?
    Our R&D team provides technical documentation and consultation to assist with custom programming and integration.


Contact Us for OEM Partnerships

Ready to elevate your desk frame designs? Contact JS Technology today to discuss customization options, request samples, or explore our OEM/ODM services. Visit our website or email us.
